Canon Canodate E

The Canon Canodate E is a point-and-shoot 35mm camera with automatic exposure, built-in flash, zone focusing, and a date imprint feature. It was designed for casual users who wanted simple operation, reliable snapshots, and the ability to timestamp photos for travel or family use.

1. Lens

• Fixed Canon 40mm f/2.8 lens

• 4 elements in 3 groups

• Versatile focal length for everyday shooting, sharp and reliable

2. Exposure System

• Fully automatic program exposure

• Selenium or CdS meter controls shutter speed and aperture automatically

• No manual control of shutter or aperture (simple point-and-shoot design)

3. Shutter

• Programmed electronic shutter

• Speeds: 1/30s – 1/500s (stepless, depending on light)

• Flash sync at 1/30s

4. Metering

• CdS light meter (battery powered)

• Exposure automation visible in the viewfinder

• Works together with programmed shutter/aperture for correct exposure

5. Focusing

• Zone focusing system (pictograms: portrait, group, landscape)

• Focus range: 1m – infinity

• Simple, fast focusing method for casual shooters

6. Viewfinder

• Bright optical viewfinder with parallax correction marks

• Displays focus symbols and exposure indicators

7. Film System

• Uses 35mm film (standard cartridges)

• ISO/ASA range: 25 – 400 (manual setting on dial)

• Manual film advance lever and rewind crank

8. Built-in Flash

• Pop-up electronic flash unit

• Guide Number: approx. GN 14 (ISO 100, meters)

• Flash sync: 1/30s

• Flash ready light visible in viewfinder

9. Date Imprint Feature

• Built-in date back system (year/month/day imprint directly on the film)

• Manual setting via small wheels/dials

• Separate button cell battery powers the date unit

10. Build & Design

• Compact, lightweight body with a simple layout

• Dimensions: ~125 × 75 × 60 mm

• Weight: ~420g

• Stylish 1970s design, aimed at family and travel photography

11. Power

• Main camera functions powered by a PX625 1.35V mercury battery (modern alternatives: zinc-air or adapter for SR44/CR1/3N)

• Date unit powered by a small button cell
